Sharing Artifacts Between GitLab CI Matrix Jobs: React Build Example

When working with GitLab CI/CD pipelines that involve complex deployment scenarios, particularly with multi-tenant or multi-environment setups, passing artifacts between jobs can be challenging. In this article, we'll explore a versatile approach to dynamically generate and share build artifacts across jobs using GitLab's parallel:matrix feature, focusing on a practical React application build example.

Understanding parallel:matrix and Dynamic Artifacts Challenge

GitLab's parallel:matrix feature allows you to run multiple jobs in parallel while dynamically assigning different values to environment variables. This is especially useful in CI/CD workflows where:

• You need to deploy to multiple environments or tenants concurrently
• You are building applications with different configurations
• Each parallel job requires unique parameters or branding

However, when working with these parallel jobs, handling artifacts becomes complex. When multiple parallel jobs generate different build artifacts, you need a way to ensure each artifact is uniquely identifiable and properly passed to corresponding downstream jobs. This creates a challenge: how do we generate unique builds for each parallel execution and ensure they're available to subsequent jobs? The solution we'll explore uses a naming convention for artifact directories to reliably pass environment-specific builds between matrix jobs. By using parallel:matrix, GitLab will automatically create a parallel job for each combination in your matrix, and our artifact approach ensures builds flow correctly between these jobs.

Practical Example: Multi-Tenant React Build Pipeline

Initial Setup

Here's a GitLab CI configuration that demonstrates our approach with a React application:

default:
  image: node:22.14.0-bookworm-slim

stages:
  - install-dependencies
  - build
  - deploy

.tenants:
  parallel:
    matrix:
      - VITE_TITLE: u11d
        VITE_COLOR: "#620bef"
      - VITE_TITLE: MedusaJS
        VITE_COLOR: "#ffffff"
      - VITE_TITLE: Terraform
        VITE_COLOR: "#7b42bc"
      - VITE_TITLE: AWS
        VITE_COLOR: "#ff9900"

install-dependencies:
  stage: install-dependencies
  needs: []
  script:
    - yarn
  artifacts:
    paths:
      - node_modules
    expire_in: 1 hour

build:
  stage: build
  extends:
    - .tenants
  environment: $VITE_TITLE
  needs:
    - install-dependencies
  script:
    - yarn build
    - mv dist dist-$VITE_TITLE
  artifacts:
    paths:
      - dist-$VITE_TITLE
    expire_in: 1 hour

deploy:
  stage: deploy
  extends:
    - .tenants
  environment: $VITE_TITLE
  needs:
    - build
  script:
    - echo "Deploying to $TENANT"
    - cd dist-$VITE_TITLE
    - ls # all build artifacts for $VITE_TITLE are available in `dist-$VITE_TITLE`

How It Works

1. Dependency Installation: The install-dependencies job installs required node modules and shares them as artifacts.
2. Parallel Matrix: The .tenants template defines a matrix with four different tenants, each with unique branding parameters (VITE_TITLE and VITE_COLOR).
3. Dynamic Builds: The build job runs in parallel for each tenant configuration, creating four separate builds with tenant-specific branding.
4. Artifact Naming Strategy: Each build output is renamed from dist to dist-$VITE_TITLE (e.g., dist-u11d, dist-AWS, etc.) to avoid conflicts.
5. Targeted Artifact Sharing: These uniquely named build directories are shared as artifacts between jobs.
6. Artifact Consumption: The deploy job accesses the correct build artifact by using the same naming convention (dist-$VITE_TITLE).

This approach results in a pipeline that looks like this:

Final Results

The approach produces four distinct builds with tenant-specific branding:

Working Example

A complete working example of this implementation is available in our public GitLab repository: https://gitlab.com/u11d-michal-miler/gitlab-ci-artifacts-sharing

Feel free to clone the repository and experiment with the pipeline to see how the artifact sharing works in practice.

Conclusion

The technique explained above isn't limited to React applications. You can use similar approaches to:

• Building artifacts for different platforms
• Creating configuration files dynamically for multiple environments
• Managing complex multi-tenant deployments
• Customizing builds for different client brands

The key is GitLab's powerful artifact and variable sharing mechanisms combined with a strategic naming convention, which allows you to create truly dynamic and flexible CI/CD pipelines.

Sharing artifacts in GitLab CI, especially with parallel matrix jobs, doesn't have to be complicated. By leveraging a consistent naming pattern and GitLab's built-in artifact functionality, you can create robust, flexible build pipelines that work seamlessly across multiple scenarios and environments.

In the next article, we'll explore how to extend this approach to pass dynamic environment variables between GitLab CI matrix jobs using AWS OIDC as an example.
